Goobay
Series 2.0
DisplayPort connector cable 2.0
DisplayPort male > DisplayPort male (8K/60Hz)
Goobay
Series 2.0
DisplayPort connector cable 2.0
DisplayPort male > DisplayPort male (8K/60Hz)
Article details
  • The DisplayPort cable (DisplayPort to DisplayPort) transmits high-resolution video signals and HD audio signals e.g. from a computer or laptop to a monitor or beamer.
  • supports high quality resolutions up to 8K (60Hz) and delivers crisp images
  • smooth images (no judder) by supporting high refresh rates up to 240 Hz especially for gaming (depending on graphics card and monitor)
  • Backward compatible to 4K Ultra HD 2160p (120 Hz), gold-plated contacts and double shielding guarantee improved signal transmission
  • The connector lock ensures a secure hold and optimal signal transmission. It can also be easily unlocked via the push button.
  • to avoid short-circuit damage, pin 20 is not connected (no power supply)
Technical specifications
Connections
Connection, type
DisplayPort male
Connection 2, type
DisplayPort male
Connection, contact material
gold-plated
Connection, length
47 mm
Connection, width
20 mm
Connection, height
12 mm
Connection 2, length
47 mm
Connection 2, width
20 mm
Connection 2, height
12 mm
Connection, housing material
ABS
Cable
Cable length
1 m
AWG
28
Cable type
round cable
Inner conductor material
CU (copper)
Material cable sheath
PVC
Number of shieldings
2 x
Cable sheath diameter (approx.)
7.3 mm
Kink protection
both sides
Signal transmission
other supported standards
HDCP 2.2, HDR (High Dynamic Range)
max. transmission rate
40 Gbit/s
max. resolution
8K Ultra HD 4320p (60 Hz), 4K Ultra HD 2160p (120 Hz), Full HD 1080p (240 Hz)
supported colorspaces
True Color (24 Bit), Deep Color (30 Bit)
General
Packaging type
Bulk
Consumption Unit
1 pc. in polybag
product.attribute.techdat-general-goobay-version
DP 1.4
Color
Markings
CE, WEEE
£7.99 RRP
Packing units:
1 / 30 / 60
Packaging type
Cable length
Item: 58532
EAN: 4040849585326
