Goobay
Series 2.1 8K
Optical Hybrid High Speed HDMI™ Cable with Ethernet (AOC)
High-speed cable for 8K @ 60 Hz/ 4K @ 120 Hz for long transmission distances
Goobay
Series 2.1 8K
Optical Hybrid High Speed HDMI™ Cable with Ethernet (AOC)
High-speed cable for 8K @ 60 Hz/ 4K @ 120 Hz for long transmission distances
Article details
AOC technology (Active Optical Cable) has built-in transceiver modules that convert the electrical signal into an optical one and convert it back into an electrical signal at the end of the line. (The signal direction must be observed when connecting.)
  • High-resolution signal transmission with up to 8K @ 60 Hz or 4K @ 120 Hz (downward compatible) offers optimal enjoyment. In addition, the cable supports all common features such as ARC (Audio Return Channel), HDCP or 3D.
  • The narrow metal plugs with kink protection also fit in tight spaces and are extremely robust. The gold-plated connections with low contact resistance ensure the best possible signal transmission.
  • The optimal transmission option for long distances. The fiber optic cable combines the advantages of optimal transmission speed and low susceptibility to interference, especially for long cable runs without amplification.
  • AOC technology (Active Optical Cable) converts the electrical signal into an optical signal and back into an electrical signal at the end of the line. (The signal direction must be observed when connecting.)
  • New HDMI™ standard for flawless film and gaming experiences, for film lovers and gamers
  • especially for games consoles with high-resolution images (4K @ 120 Hz, 8K @ 60 Hz) such as Sony Playstation 5 (PS 5) or Microsoft Xbox Series X.
Technical specifications
Connections
Connection, shielding
yes
Connection, length
42.1 mm
Connection, width
20.4 mm
Connection, type
HDMI™ male (type A)
Connection, height
11.4 mm
Connection 2, type
HDMI™ male (type A)
Connection 2, length
42.1 mm
Connection 2, width
20.4 mm
Connection 2, height
11.4 mm
Connection, housing material
PVC
Connection, contact material
Cable
Cable length
10 m
Cable type
round cable
Inner conductor material
Cable sheath diameter (approx.)
5.2 mm
Kink protection
yes
Ferrite core
no
Signal transmission
max. transmission rate
48 Gbit/s
other supported standards
HDR (High Dynamic Range), HDMI™ Ethernet Channel (HEC), 4K 3D, 21:9 Cinemascope, HDCP 2.2, Enhanced Audio Return Channel (eARC), Consumer Electronics Control (CEC)
max. resolution
4K Ultra HD 2160p (120 Hz), 8K Ultra HD 4320p (60 Hz)
General
Packaging type
Bulk
Consumption Unit
1 pc. in shrink-pack
product.attribute.techdat-general-goobay-version
2.1
Color
black
Material
PVC
Markings
WEEE, CE
Operating temperature from
0 °C
Operating temperature up to
50 °C
Warranty
2 years
Packing units:
1 / 10
Packaging type
Cable length
Item: 49883
EAN: 4040849498831
