80 dB Coax- Antenna Cable, 2x Shielded, CU, white
for digital SAT- and CATV-cable systems
80 dB Coax- Antenna Cable, 2x Shielded, CU, white
for digital SAT- and CATV-cable systems
Article details
- Digital-ready for SDTV using DVB-S, DVB-T, DVB-C
- Double signal shield for adequate protection over long distances
- Inner conductor made of specially conductive and flexible copper
- Meter scaling on the cable simplifies building installation
- The Goobay coaxial-/antenna cables meet the CPR (Construction Products Regulation) and thus comply with the Eca fire protection class.
Technical specifications
Cable
Cable type
coaxial cable
Cable length
100 m
Cable sheath diameter (approx.)
4.6 mm
Inner conductor material
CU (copper)
Meter scaling
yes
Dielectric diameter
3.2
Number of shieldings
2 x
Type 1, shielding
double foil (aluminium)
Type 2, shielding
braid (aluminium) 64x
inner conductor, core diameter
0.7 mm
Shielding efficiency
80 dB
Fire class (CPR)
Eca
Signal transmission
Impedance
75 Ω
General
Outer sheath material
PVC
Color
white
Markings
ECA_CPR, CE
Operating temperature from
-20 °C
Operating temperature up to
70 °C
Packaging type
Cable spool-drum
Dimensions / Weight
Consumption Unit
1 pc. cable reel
Weight
2420 g
Downloads
Item: 67101
EAN: 4040849671012
