Product and packaging similar. Subject to modifications and errors.
CAT 6 A Flat Patch Cable U/UTP, red
copper conductor (CU)
With the Goobay CAT cable, you can connect PCs, laptops, routers, switches, smart TVs, games consoles, NAS systems and many other devices quickly and reliably. The practical, reliable solution for home networks, working from home and professional work environments. Goobay patch cables are available in a wide range of categories, shielding options and lengths – for full flexibility in your network.
- Prewired, unshielded LAN cable with 2x RJ45 plugs for connecting network components
- Extremely flat Ethernet cable with low bending radius and high flexibility, ideal for space-saving installation under floors or skirting boards.
- Network flat cable with external dimensions of approx. 1.5 x 6.0 mm
- Short RJ45 connector without latch protection
- High-quality copper conductor (CU) and gold-plated contacts guarantee an excellent, powerful network connection.
- Bend protection and a sturdy PVC jacket effectively protect the network cable from breakage.
- Network connector: pair sequence according to EIA/TIA 568B
Connections
| Contacting |
EIA/TIA-568 B |
| Latch protection |
no |
| Connection, type |
RJ45 male (8P8C) |
| Connection 2, type |
RJ45 male (8P8C) |
| Kink protection |
both sides |
Cable
| Specification |
CAT 6 A |
| Cable type |
flat cable |
| Cable length |
0.5 m |
| Material cable sheath |
PVC |
| Inner conductor material |
CU (copper) |
| AWG |
32/7 (stranded) |
| bending radius > |
12 mm |
| height of cable sheath |
1.5 mm |
| width of cable sheath |
6 mm |
| Shielding class |
U/UTP |
Signal transmission
| max. transmission rate |
10 Gbit/s |
| max. bandwidth |
500 MHz |
General
| Color |
red |
| Markings |
WEEE, CE |
| Operating temperature from |
-20 °C |
| Operating temperature up to |
60 °C |
| Packaging type |
Cable Tag |
Dimensions / Weight
| Consumption Unit |
1 pc. bulk |
