RCA/HDMI™ Converter
converts analogue audio and video signals into digital HDMI™ signals
RCA/HDMI™ Converter
converts analogue audio and video signals into digital HDMI™ signals
Article details
- picture input can be freely manually selected
- very easy to use
- easy to install without additional software
Technical specifications
Labelling
Disclaimer
all brand names are registered trademarks of their owners., The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade Dress and
the HDMI Logos are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
Connections
Connection, type
3x RCA female
Input, type
3x RCA female
Connection 2, type
HDMI™ female (Type A)
Output, type
HDMI™ female (Type A)
ErP
Average active efficiency
79 %
Efficiency at low load (10 %)
72.9 %
No-load power consumption
0.09 W
Device connections
number of inputs
1
Number of outputs
1
Signal transmission
supported audio standards
3D
General
Color
black
Material
metal
Markings
CE, WEEE
Operating temperature from
0 °C
Operating temperature up to
70 °C
Packaging type
Retail Box
Dimensions / Weight
Consumption Unit
1 pc. in cardboard box
Length
155 mm
Width
70 mm
Height
23 mm
Weight
267 g
Scope of delivery
Scope of delivery
manual, power supply
accessory - Power supply
Cable Length
1.4 mm
Weight
77.5 g
Dimensions
60,9x27,1x72,6
Output current
2 A
Input AC frequency
50/60 Hz
Input voltage
100-240 V
Input current
0.4 A
Output voltage
5.0 V
Output power
10.0 W
Language Scope
packaging
en, de, fr, it
Operation manual
en, de, fr, it
Downloads
Item: 58969
EAN: 4040849589690
