S-Video cable
flexile connection cable for demanding users
Every single image is virtually noiseless with true color: With this, you will get the most out of you system. Small wonder, because the cleanly separate transmission of brightness (luminance) and color information (chrominance), as well as multiple layers of signal shielding, pure materials, and precise processing, no detail remains hidden.
- 75 Ω defined characteristic impedance
- pure copper conductor and 2-way shielding for clear signal quality
- 24 carat gold-plated contacts for minimum transmission resistance
Connections
| Connection, housing material |
ABS, PVC |
| Connection, type |
Mini-DIN 4 male (S-Video) |
| Connection, length |
39.8 mm |
| Connection 2, type |
Mini-DIN 4 male (S-Video) |
| Connection, contact material |
gold (24 kt) |
| Connection, shielding |
yes |
| Kink protection |
both sides |
Cable
| Material cable sheath |
PVC |
| Cable length |
15 m |
| Cable type |
round cable |
| Inner conductor material |
CU (copper) |
| Cable sheath diameter (approx.) |
6.5 mm |
| Type 2, shielding |
braid (copper) 64x |
| AWG |
27 |
| Ferrite core |
no |
Signal transmission
| Signal amplification |
no |
| Impedance |
75 Ω |
General
| Operating temperature from |
-10 °C |
| Operating temperature up to |
80 °C |
Dimensions / Weight
| Consumption Unit |
1 pc. in cardboard box |
