Goobay
SAT antenna cable (135 dB), 4x shielded
gold plated, F male 90° > F male 90°
Goobay
SAT antenna cable (135 dB), 4x shielded
gold plated, F male 90° > F male 90°
Article details
ideal for high-resolution transmissions (HDTV, Full HD, Ultra HD (UHD/4K and higher)) for both digital SAT signals such as DVB-S and DVB-S2. Reliable connection between the wall/multimedia outlet and the receiving device, such as a TV/SAT receiver, cable modem, cable router etc.
  • inner conductor made of ultrapure OFC solid copper for optimal conductive and transmission properties, ensuring virtually loss-free signal routing
  • 4-layer, ultrathick shielding material (made of ultrathick 2-layer mesh and 2-layer film) with 135 dB shielding capability
  • the perfect balance of shielding and flexibility – the ideal shielding for ensuring perfect reception and disruption-free transmission
  • massive solid metal connector with gold-plated contacts – for optimal durability, stability and precision
  • wide, easy-grip metal caps for effortless, tool-free screwing
  • optimised bend protection and flexible cable sleeving prevent the maximum bending radius from being exceeded
Technical specifications
Connections
Connection, type
F male 90°
Connection, housing material
aluminum
Connection 2, type
F male 90°
Connection, contact material
gold-plated
Connection, shielding
yes
Cable
Cable length
1 m
Material cable sheath
PVC
Inner conductor material
CU (copper)
Cable type
coaxial cable
Dielectric diameter
5
inner conductor, core diameter
1.02
Cable sheath diameter (approx.)
8 mm
Number of shieldings
4 x
Type 1, shielding
foil (aluminium)
Type 2, shielding
braid (aluminium) 128x
Kink protection
both sides
Shielding efficiency
135 dB
Type 3, shielding
foil (aluminium)
Type 4, shielding
braid (aluminium) 128x
Signal transmission
Impedance
75 Ω
General
Packaging type
Retail Polybag
Color
white
Markings
WEEE, CE
Special feature
big nut
Packing units:
1 / 50 / 100
Packaging type
Cable length
Item: 70481
EAN: 4040849704819
