SAT antenna cable
F-coaxial cable with a shielding rating of > 95 dB
Noise free television reception is primarily a question of the right material. This coaxial cable is specifically designed to satisfy demanding requirements in high-definition television formats. Thanks to two layers of signal shielding, pure materials, and precise processing, it transfers the HDTV and DVB signals without any loss to the receiver. Therefore, you can be sure that you get the experience exactly as it was meant to be.
- pure copper conductor and 2-way shielding for clear signal quality
- particularly suitable for digital satellite TV
- 24 carat gold-plated contacts for minimum transmission resistance
Connections
| Connection, housing material |
ABS, PVC |
| Connection, type |
F male |
| Connection, length |
39.8 mm |
| Connection 2, type |
F male |
| Connection, contact material |
gold (24 kt) |
| Connection, shielding |
yes |
Cable
| Material cable sheath |
PVC |
| Cable length |
5 m |
| Cable type |
round cable |
| Inner conductor material |
CU (copper) |
| Diameter ferrite core |
14 mm |
| Shielding efficiency |
95 dB |
| Cable sheath diameter (approx.) |
6 mm |
| Type 2, shielding |
braid (copper) 96x |
| AWG |
22 |
| Ferrite core |
yes |
Signal transmission
| Signal amplification |
no |
| Impedance |
75 Ω |
General
| Color |
blue |
| Markings |
WEEE, CE |
| Operating temperature from |
-10 °C |
| Operating temperature up to |
80 °C |
Dimensions / Weight
| Consumption Unit |
1 pc. in cardboard box |
warranty
