| Number of inputs | 4x SAT,1x TER | |
| Subscriber outputs | 6 | |
| Connectors | F- female | |
| Frequency range (MHz) | SATÂ | 950-2150 |
| Â | TERÂ | 47-862 |
| Gain (dB) | SATÂ | -4 to 6 |
| Â | TERÂ | 0 to 6 |
| Isolation (dB) | TER to SATÂ | 30 |
| Isolation (dB) | SAT to TERÂ Â | 28 |
| Isolation cross polarisation H/V (dB) | 25 | |
| Isolation (dB) | out - out TERÂ | 22 |
| Isolation (dB) | out - out SATÂ | 30 |
| Return loss (dB) | SAT inputs  | 10 |
| Return loss (dB) | SAT outputs | 8 |
| Return loss (dB) | TER inputs | 8 |
| Return loss (dB) | TER outputs  | 8 |
| Output level (dBμV) | SAT (IMD3 - 35 dB) | 100 |
| Output level (dBμV) | TER (IMD3 - 60 dB) | 88 |
| Impedance input/output (Ω) | 75 | |
| Current consumption from receiver(mA) | 100 | |
| LNB remote current(mA) | 800 | |
| Input | 100 to 240 V AC, 50/60 Hz | |
| Max. standby power(Watt) | 3,5 | |
| Max. power consumption(Watt) | 45 | |
| Switching  (VDC) | 13V -18V 13V/22kHz 18V/22 kHz | |
| Operating Temperature | 0 to 50° C | |
| Storage Temperature | -40 to 70°C | |
